Matrx Loxx Headrest Hardware

The Invacare Matrx® LOXX Headrest Hardware provides secure, adjustable support for positioning the head comfortably and effectively within a wheelchair seating system. With tool-less lever adjustments, dual pivot balls, and slide bar positioning, it allows the head support to be fine-tuned for improved alignment, comfort, and daily positioning needs.

Designed to work with Invacare Matrx backrests and Matrx headrest pads, the LOXX hardware offers a reliable adjustment system for Matrx seating setups and may also be compatible with select non-Matrx backrests when properly configured. Its intuitive design makes it easier to adjust head support positioning without unnecessary complexity.

Key Features

• Adjustable Head Support Positioning: Helps fine-tune head support for improved comfort, alignment, and daily wheelchair positioning
• Tool-Less Lever Adjustments: Allows quick, intuitive headrest positioning without requiring tools for routine adjustment
• Extensive Positioning Adjustability: Offers 360° rotation, depth adjustment, pad tilt, and vertical-post rotation in 90° increments to help fine-tune head support positioning
• Dual Pivot Ball Design: Provides flexible angle adjustment to help position the head support for effective fit
• Slide Bar Adjustment: Helps refine pad orientation and positioning for improved support
• Curved 15" Vertical Post: Supports lateral or forward mounting positions for greater setup flexibility
• Patent-Pending Locking Design: Helps ensure the hardware holds securely in the locked position
• Crash Tested: Tested for safety and durability in wheelchair seating applications
• High-Visibility Protective Safety Tip: Urethane safety tip helps protect the end of the vertical post while improving visibility
• Designed for Matrx Seating Systems: Built to work with Invacare Matrx® backrests and headrest pads. Compatibility varies for non-Matrx® backrests.
• Includes Mounting Kit Plate: Comes with the mounting kit plate needed for installation to Invacare Matrx backrests
• Hardware-Only: Includes the headrest hardware only; headrest pad is sold separately

Additional Features & Details

• Includes LOXX headrest hardware and mounting kit plate
• Headrest pad is sold separately
• Designed for use with Invacare Matrx backrests and Matrx headrest pads
• May be compatible with select non-Matrx seating products when the mounting interface is confirmed
• Conversion hardware may be required for certain non-Matrx configurations
• Professional installation or setup is recommended for proper positioning and secure attachment
• Select a compatible headrest pad separately based on the user’s support needs

Multi-Point Adjustment for Precise Head Support Positioning

The Invacare Matrx® LOXX Headrest Hardware is designed to provide extensive positioning flexibility for wheelchair head support. Multiple adjustment points allow the headrest to be positioned for improved comfort, alignment, and support, helping users and seating professionals fine-tune the setup around individual positioning needs.

The hardware offers depth adjustment along the horizontal support arm, 360° rotation at key adjustment points, and tilt adjustment at both the headrest pad connection and hardware joint. The headrest pad connection provides up to 80° of tilt, while the hardware joint provides up to 50° of tilt for additional positioning control.

For added setup flexibility, the vertical post connection allows 360° rotation in 90° increments. This helps accommodate different mounting orientations and positioning requirements while keeping the head support system secure and adjustable.

Tool-Less Adjustment for Easier Positioning

The LOXX hardware uses tool-less lever adjustments to simplify head support positioning and reduce the need for frequent tool-based changes. This makes it easier to fine-tune the headrest when seating needs change or when a more precise fit is needed.

The dual pivot balls and slide bar provide additional flexibility, allowing the head support to be angled and positioned for improved alignment. This is especially helpful in wheelchair seating systems where head position can affect comfort, posture, visual orientation, and overall support.

Designed for Matrx Seating Systems

The Invacare Matrx LOXX Headrest Hardware is designed to work with Invacare Matrx backrests and Matrx headrest pads, making it a natural choice for Matrx seating systems. The hardware provides the adjustment and mounting foundation needed to build or replace a compatible Matrx head support setup.

Because this product includes the hardware only, the headrest pad must be ordered separately. Select a compatible headrest pad based on the user’s positioning goals, wheelchair setup, and support needs.

Compatibility with Select Non-Matrx Backrests

The Matrx LOXX Headrest Hardware may also be compatible with select non-Matrx backrests when the mounting interface is appropriate. Compatibility can vary depending on the backrest brand, mounting-hole spacing, available attachment surface, and whether adapter or conversion hardware is required.

For non-Matrx seating setups, confirm the backrest mounting pattern and headrest pad interface before ordering. Some configurations may require a separately sold conversion kit to connect the LOXX hardware properly.

Practical for Personal and Clinical Seating Needs

For personal wheelchair users, the Matrx LOXX Headrest Hardware provides an adjustable foundation for head support that can be configured around individual comfort and positioning needs. Its tool-less adjustment design can also make routine fine-tuning easier for caregivers or seating providers.

For clinical and facility settings, LOXX hardware is useful when a reliable, adjustable head support system is needed for wheelchair seating evaluations, rehab applications, long-term positioning needs, or replacement hardware.

Who This Headrest Hardware Is Best For

The Invacare Matrx LOXX Headrest Hardware is appropriate for users and care environments that need:

• Adjustable wheelchair headrest hardware for head support and positioning
• Tool-less head support adjustment for easier setup and fine-tuning
• Hardware for use with Invacare Matrx backrests and Matrx headrest pads
• A secure mounting system for compatible headrest pads
• Dual pivot ball and slide bar adjustment for customized positioning
• A headrest hardware option that may work with select non-Matrx backrests after compatibility is confirmed

Need Help Confirming Compatibility?

Need help verifying whether the Matrx LOXX Headrest Hardware will work with your backrest or headrest pad? Our team can assist with product guidance to help confirm compatibility with your seating system, mounting interface, and head support setup before ordering.
